The VSKYLABS Robinson R44 Raven II Project
JetManHuss - VSKYLABS (c) 2023 All Rights Reserved

A High Definition Robinson R44 Raven II Helicopter Simulation

Separate native products for X-PLANE 12 and X-PLANE 11, for your selection.

MINIMUM HARDWARE REQUIREMENTS FOR X-PLANE 12

Disk Space: 25GB
CPU: Intel Core i3, i5, i7, or i9 CPU with 4 or more cores, or AMD Ryzen 3, 5, 7 or 9.
(Those with other CPUs should try the demo before purchasing.)
Memory: 8 GB RAM
Video Card: a Vulkan 1.3-capable video card from NVIDIA or AMD with at least 2 GB VRAM
Note: Intel GPUs are not supported by X-Plane 12.

The VSKYLABS development of the Robinson R44 project for X-Plane flight simulator was acknowledged by the Robinson Helicopter Company. However, it is an independent VSKYLABS project which is not related, affiliated and/or endorsed with the Robinson Helicopter Company.

Project Introduction:

The Robinson R44 Raven II is a high performing, four-seat aircraft. It has been the world’s best-selling GA helicopter for more than two decades. The R44’s aerodynamic fuselage optimizes airspeed and fuel economy. It is powered by Lycoming IO-540 fuel injected engine and it cruises at 110 knots and can fly 300 nautical miles and up to 14,000 feet.

This project is part of the VSKYLABS 'Test-Pilot' series, designed specifically for use with X-Plane cutting edge Flight Model. The VSKYLABS R44 project is setting up a highly detailed and highly accurate Robinson R44 Raven II simulation along with full VR compatibility, stretching X-Plane capabilities to its limits.

Project Main Features:

• VSKYLABS 'Test-Pilot' Project.
• Robust and Highly Defined flight dynamics model of the Robinson R44 Raven II helicopter, built around the powerful, native X-Plane Flight Model environment.
• Highly detailed model of the Robinson R44 Raven II helicopter.
• Autorotation capable.
• Comprehensive systems which were designed to follow the real R44 Raven II POH, as authentically as possible within X-Plane 11 flight simulator limitations.
• Fully functional VR (Virtual Reality) Ready: highly interactive cockpit environment including levers, switches, guards, 3D checklist viewer, modular cyclic and more.
• Equipped with Robinson's classic 7 holes analog panel.
• R44 Auxiliary fuel system.
• Removable doors.
• Fully featured GNS530.
• Built-in Avitab Compatibility (Avitab plugin not included).
• Multi-Layer FMOD sound pack.
• The project is under constant development: development road-map is including flight model refinements, enhanced systems depth, additional liveries and other improvements.
• Autoupdater based on the SkunkCrafts autoupdater (XP12 only) - all updates are being pushed smoothly without the need to re-download the entire base package (base package will be updated every once in a while to minimize the gap).
• Highly responsive VSKYLABS support forums.

Pilot's Operating Handbook

VSKYLABS Robinson R44 Raven II - ESSENTIALS manual

VSKYLABS Robinson R44 Raven II - POH / manual

Update Log

VSKYLABS Robinson R44 Raven II Project
JetManHuss - VSKYLABS (c) 2022 All Rights Reserved
